Monacor VRB-100M1 1Kohm, 0.2W, linjär

  • 34 kr

With slotted 6 mm shaft, for 18-tooth push-on buttons, with nut fixing and PCB solder connections.EgenskaperResistance1 kOCharacteristiclinearPower rating0.2 WI

I lager.

With slotted 6 mm shaft, for 18-tooth push-on buttons, with nut fixing and PCB solder connections.

Egenskaper

Resistance1 kO
Characteristiclinear
Power rating0.2 W
Insulating resistance< 100 MO/ DC 500 V
Test voltage∿ 500 V/1 min.
Tracking error±3 dB, 0/-40 dB
Rotation angle300° ±5°
Clicks-
